The TruCap is the base tightening platform without an integrated cap feeder — the same heavy-duty spring-loaded capping disc system as the rest of the TruCap-X line, for lines where caps are placed manually or by a separate feeder system.
The TruCap is the tightening core of the TruCap-X platform without a built-in cap feeder — same welded 304 stainless steel C-frame, same independent spring-loaded capping discs, same running torque adjustment with the pneumatic clutch option. It's the right fit if you already have a cap feeding system in place, or if caps are placed by hand ahead of the tightener.
Capping heads are 316L stainless steel and FDA-approved polymer, adjustable while running without opening the safety covers. Container height adjusts from 1" to 14" tall (optional power height adjustment), and the machine works across a wide range of containers with no change parts needed.
Better torque control and misalignment forgiveness.
Single gearbox driven, scales to your throughput needs.
Adjustable while operating, with pneumatic clutch option.
Fits lines with a feeder already in place, or manual placement.
No feeder hardware means a simpler, lower-cost machine.
Upgrade path to any TruCap-X feeder configuration.
Independent width, taper, and angle adjustment.
Front covers with safety interlock switches standard.
Works across a wide range of containers as-is.
| Model | TruCap |
| Frame Construction | 304 Stainless Steel, welded C-frame |
| Spindle Configurations | 4, 6, or 8, single gearbox driven |
| Capping Head Material | 316L stainless steel / FDA-approved polymer |
| Cap Diameter Range | 8mm – 130mm |
| Container Height Range | 1" – 14" (optional power height adjustment) |
| Cap Feeder | None included — pairs with existing feed or manual placement |
| Power | 120V, single phase, 50/60Hz, 15A |
| Air Requirement | 5 CFM @ 80 PSI (only required with pneumatic clutches) |
