The TruCap-X-WFall-VP is an automatic inline bottle capper built on a heavy-duty 304 stainless steel C-frame, with independent spring-loaded capping discs for better torque control and misalignment forgiveness. Adds vertical cap placement to the standard waterfall feeder — caps are set onto the bottle from directly above rather than at an angle, useful for taller or narrower-neck containers where placement angle matters.
The TruCap-X-WFall-VP runs on a welded 304 stainless steel C-frame designed to mount directly over your existing conveyor. Independent spring-loaded capping discs handle torque and bottle misalignment better than fixed-spindle designs, and torque can be adjusted while the machine runs when the pneumatic clutch option is purchased. Capping heads are stainless steel and FDA-approved polymer, adjustable while running without opening the safety covers.
Adds vertical cap placement to the standard waterfall feeder — caps are set onto the bottle from directly above rather than at an angle, useful for taller or narrower-neck containers where placement angle matters. Container height adjusts from 1" to 14" tall (optional power height adjustment), and the machine works across a wide range of containers with no change parts needed.
Better torque control and misalignment forgiveness.
Single gearbox driven, scales to your throughput needs.
Adjustable while operating, with pneumatic clutch option.
Gravity-fed chute, ideal for large, flat cap styles.
Caps set straight down onto the bottle from above.
Placement angle reduces cross-threading on tricky containers.
Independent width, taper, and angle adjustment.
Front covers with safety interlock switches standard.
Works across a wide range of containers as-is.
| Model | TruCap-X-WFall-VP |
| Frame Construction | 304 Stainless Steel, welded C-frame |
| Spindle Configurations | 4, 6, or 8, single gearbox driven |
| Capping Head Material | Stainless steel / FDA-approved polymer |
| Cap Diameter Range | 8mm – 130mm |
| Container Height Range | 1" – 14" (optional power height adjustment) |
| Cap Feeder | Waterfall with vertical cap placement |
| Power | 220V, single phase, 50/60Hz, 15A |
| Air Requirement | 10 CFM @ 80 PSI (only required with pneumatic clutches) |
